ER80S-Ni1
AWS A5.28 ER80S-Ni1
80S-Ni -1 is for welding fine grained and low alloy nickel steels producing highimpact values even at low temperature such as -50° F.
TYPICAL WIRE CHEMISTRY (%)
- | ER80S-Ni1 | AWS Spec |
|---|---|---|
C | 0.085 | 0.12 max. |
Mn | 1.06 | 1.25 |
Si | 0.62 | 0.40-0.80 |
P | 0.007 | 0.025 max. |
S | 0.009 | 0.025 max. |
Mo | 0.22 | 0.35 max. |
Cu | 0.10 | 0.35 max. |
Ni | 0.85 | 0.80-1.10 |
Cr | 0.09 | 0.15 max. |
Typical mechanical properties of weld metal (C02 shielding gas)
- | ER80S-Ni1 | AWS Spec |
|---|---|---|
Yield strength (psi) | 72,500 | 68,000 min |
Ultimate tensile strength (psi) | 89,900 | 80,000 min |
Elongation in 2" (%) | 25 | 24 min |
Charpy V-notch at -50 °F (ft. lbs) | 20 min |
