Stainless Flux Coated TIG
These flux coredrods are primarily used for the root pass on piping where backing and purging gas may not be possible or desirable. This rodshould be used as a basic tig rodon DCEN, however caution is advised due totheeasily removable slag covering thatmust be removed prior to addition welding.
TYPICAL WIRE CHEMISTRY (%)
- | R308L | R309L | R316L | R347 |
|---|---|---|---|---|
C | 0.03 | 0.03 | 0.03 | 0.03 |
Cr | 18.0-21.0 | 22.0-25.0 | 17.0-20.0 | 18.0-21.0 |
Ni | 9.0-11.0 | 12.0-14.0 | 11.0-14.0 | 9.0-11.0 |
Mo | 0.5 | 0.5 | 2.0-3.0 | 0.5 |
INTENDED USE
R308L: Welding of 18Cr & 8Ni such as 304, 304L
R309L: Welding of carbon steel to austenitic stainless
R316L: Primarily use on 316 or 316L
R347: Primarily use on 347
Typical mechanical properties of weld metal (C02 shielding gas)
- | R308L | R309L | R316L | R347 |
|---|---|---|---|---|
Ultimate Tensile Strength (psi) | 75,000 | 75,000 | 70,000 | 75,000 |
Elongation in 2" (%) | 35 | 30 | 30 | 30 |
